portant;" />· 产品介绍 /Products：
|
产品编号 Item number |
21449D |
21449C |
21449 |
21449A |
|
产品型号 Model |
CPC-85H | CPC-100B | CPC-130A | CPC-160A |
|
出 力(KN) Crimping force |
80KN | 80KN | 80KN | 80KN |
|
剪 切 范 围
Cutting range |
铠装电缆 armored CU/AL cable Φ85mm max |
铠装电缆 armored CU/AL cable Φ100mm max |
铠装电缆 armored CU/AL cable Φ130mm max |
铠装电缆 armored CU/AL cable Φ160mm max |
|
行 程 Stroke |
85mm | 100mm | 130mm | 160mm |
|
长 度 Length |
approx.480mm | approx.620mm | approx.650mm | approx.750mm |
|
重量（KG） Weight |
approx.N.W6.7KG G.W9.2KG |
approx.N.W12KG G.W15KG |
approx.N.W13.35KG G.W16.5KG |
approx.N.W15.35KG G.W18.5KG |
|
包 装 Package |
木箱wooden case | 木箱wooden case | 木箱wooden case | 木箱wooden case |
· 配置说明 /Configuration：
◆ 配手动液压泵或者电动液压泵
◆ Working with a manual hydraulic pump or an electric hydraulic pump.
